Product Description
CPT Series Marine Injection Pump
CPT type jet pump has the advantages of simple structure, no moving parts, long service life, etc., has good self absorption performance, can work continuously and stably. Mainly used in ship drainage system, is also widely used in petrochemical, environmental protection, water conservancy, building materials and other industries, to draw a line of fresh water, mixed with liquid, river dredging, sewage treatment, transportation, etc.
Technical Data of CPT Series Marine Injection Pump:
| Jet Pump Type | Capacity | Delivery | Suction head | Working Pressure | Water Consumption | Weight |
| (M3/h) | (m) | (m) | (MPa) | (M3/h) | (Kg) | |
| CP5-0.7T | 5 | 8 | 4 | 0.7 | 3.6 | 14 |
| CP5-0.3T | 5 | 5 | 4 | 0.3 | 6 | 17.2 |
| CP10-1.0T | 10 | 20 | 5 | 1 | 16.7 | 16 |
| CP10-0.7T | 10 | 8 | 4 | 0.7 | 7 | 20 |
| CP10-0.3T | 10 | 5 | 4 | 0.3 | 12 | 20.5 |
| CP15-0.5T | 15 | 11 | 7 | 0.5 | 24 | 26 |
| CP15-0.3T | 15 | 5 | 4 | 0.3 | 19 | 25.8 |
| CP15-0.7T | 15 | 15 | 4 | 0.7 | 27 | 28.5 |
| CP20-0.7T | 20 | 8 | 4 | 0.7 | 14 | 28.5 |
| CP20-0.3T | 20 | 5 | 4 | 0.3 | 24 | 26 |
| CP30-0.7T | 30 | 8 | 4 | 0.7 | 21 | 32 |
| CP30-0.3T | 30 | 5 | 4 | 0.3 | 36 | 50 |
| CP40-0.3T | 40 | 5 | 4 | 0.3 | 47 | 49.5 |
| CP50-1.0T | 50 | 20 | 5 | 1 | 64 | 52 |
| CP50-0.7T | 50 | 8 | 4 | 0.7 | 35 | 48 |
| CP50-0.3T | 50 | 6 | 3 | 0.3 | 55 | 56 |
| CP60-0.7T | 60 | 6 | 6 | 0.7 | 50 | 55.5 |
| CP80-0.7T | 80 | 10 | 5 | 0.7 | 90 | 75 |
| CP100-0.7T | 10 | 9 | 2 | 0.7 | 60 | 71.5 |
| CP100-0.3T | 100 | 6 | 3 | 0.3 | 110 | 73 |
| CP100-0.2T | 100 | 7 | 3 | 0.2 | 305 | 120 |
| CP200-0.7T | 200 | 9 | 2 | 0.7 | 120 |
If You Are Interested In CPT Series Marine Injection Pump, Please Contact Us For More Details.
