YLG Series Marine Pressure Water Tank

  • UC Marine
  • Marine Hydrophore
  • Pressure Water Tank
  • CCS,GL,EC,BV,LR,ABS,NK
  • China

Product Description

YLG Series Marine Pressure Water Tank

The pressure water tank can be used to provide fresh water for living and cleaning of ship and Drilling platforms.

Principle Description:

This device uses pressured water by pump produced by shipyard,to compress the air inside of tank,in order to maintain the water in cabinet body under a suitable air pressure.So as to provide fresh water to the crews.

Main technical requirements:

Type YLG Series
Volume 0.12-3.0m3
Working pressure 0.6MPa
Design pressure 0.7MPa
Strength test pressure 1.05MPa
Air tightness test pressure 0.875MPa
Open pressure of safety valve 0.63MPa
Working temperature 0~45℃
Design temperature 50℃

If You Are Interested In YLG Series Marine Pressure Water Tank,Please Contact Us For More Details.

YLG Series Marine Pressure Water Tank.jpg
