ZYG Series Marine Combination Pressure Water Tank

  • UC Marine
  • Marine Hydrophore
  • Combination Pressure Water Tank
  • CCS,GL,EC,BV,LR,ABS,NK
  • China

Product Description

ZYG Series Marine Combination Pressure Water Tank

This series of pressure water tank is suitable for ship fresh water pipes and sea water pipes,pumps;pressure swith,electric control box and hydrophone are installed together.

It is compact and beautiful appearance.easy to install and maintain,and it is an ideal unit for water supply system.


Main technical requirements:

Model                 ZYG Series
0.12 0.2 0.3 0.5 1 1.5 2
Volume(m3) 0.12 0.2 0.3 0.5 1 1.5 2
Working pressure(MPa) 0.4
Design pressure (MPa) 0.44
Test pressure (MPa) 0.66
Take-off pressure of safety valve(MPa) 0.42
Working temperature(℃) 0~45
Design temperature(℃) 50
Water pump Model 1.5CWX-1.5/1.5A 1.5CWX-2/2A 1.5CWX-3/3A
Flow rate(m3/h) 3 6.5 10
Pumping head (m) 40 40 40
Power(kW) 2.2 3 4

If You Are Interested In ZYG Series Marine Combination Pressure Water Tank,Please Contact Us For More Details.

ZYG Series Marine Combination Pressure Water Tank.jpg
