Product Description
Both Sides of A Canopied Reversible Inflatable Liferafts
*Regulation 4、26 & 34, Chapter III of SOLAS 1974, as amended
*Chapter I and IV of MSC48.(66) International Life-saving Appliance Code (LSA Code) and MSC.218(82)、MSC.293(87)
*Sections V of Parts1; Sections V of Parts 2of MSC.81(70) Revised Recommendation on Testing of Life-saving Appliances and MSC.226(82)、MSC.295(87)、MSC323.(89)
*China MSA“Regulations for the Statutory Surveys of Ships and Offshore Installations-Technical Regulations for the Statutory Surveys of Sea-going ships Engaged in Domestic Voyages”2011, Part4, Ch.3 and Revision 2012, It can be used in the ships engaged on international voyages.
*CCS type approval certificate
Technical Data of Inflatable Liferafts:
| Type | KHR-6 | KHR-10 | KHR-25 | KHR-30 | KHR-50 | KHR-65 | KHR-100 | |
| Physical form | Regular octagon | Is dodecagon | Regular decagon | Hexadecagon | Rectangular dodecagon | |||
| Capacity | 6 | 10 | 25 | 30 | 50 | 65 | 100 | |
| Length ,mm, ±1000 | 2720 | 2720 | 4160 | 4480 | 5760 | 6630 | 10570 | |
| Width, mm, ±1000 | 2720 | 2720 | 4160 | 4480 | 5760 | 6630 | 5700 | |
| Height , mm, ±50 | 1500 | 1500 | 2200 | 2400 | 2700 | 2700 | 2600 | |
| WP pressure，kPa | 16 | 20 | ||||||
| Specification of cylinder | 7×1 | 7×1 | 9×2 | 9×2 | 9×4 | 10×4 | 18×4 | |
| Gas volume, g | CO2, ±050 | 4250 | 4250 | 5400 | 5600 | 5600 | 6200 | 10000 |
| N2, ±020 | 400 | 400 | 400 | 400 | 400 | 400 | 1000 | |
| Container | Dia. (mm) | 670 | 670 | 730 | 770 | 805 | 805 | 1050 |
| Length(mm) | 1135 | 1135 | 1495 | 1495 | 1895 | 1895 | 2400 | |
| Total weight, kg ≤ | 90 | 100 | 190 | 205 | 320 | 420 | 800 | |
If you are interested in both sides of a canopied reversible inflatable liferafts, please contact us for more details.
