CPT-190 Table Model Magnetic Compass

  • UC Marine

  • Marine Compass

  • Magnetic Compass

  • CCS,ZY

  • China


Product Description

CPT-190 Table Model Magnetic Compass

CPT-190 Magnetic Compass is a sort of table model liquid magnetic compass. It is used for the middle and small vessels acting as steering compass. The compass is a magnetic compass class A and it is designed and manufactured on the basis of the national standard GB/T 14108-2011 (General Technical Terms of Marine Magnetic Compass Class A), its technical performance index are completely in accordance with the national standard. The product has the advantages of beautiful outline、high precision、convenient correcting difference、steady performance and legible lighting etc. It is the essential navigation instrument for the middle and small vessels.

Main technical parameters:

CPT-190 Table Model Magnetic Compass
Dial DiameterΦ190mm
Dial graduation0°~360° 1°for each grid
Using temperature-25℃~60℃
Indicating deviation     (H=35μT,T=20±3℃)≤0.5°
Half period(H=35μT,T=20±3℃)≥8.62 S
Friction deviation(H=35μT,T=20±3℃)≤0.09°
Main semicircle self heterodyne correcting energy1°~45°
Quadrant self heterodyne correcting energy0.5°~10°
Inclining self heterodyne correcting energy-75~+75μT
Lighting power supplyAC 220V,DC 24V
Outline Dimension750×346×570mm
Diameter of mounting holesPitchrow 275  ApertureΦ12

If You Are Interested In CPT-190 Table Model Magnetic Compass,Please Contact Us For More Details.
